GC-T390

Basic parameters

Engine Model:Electric/KOOP/RATOGH/Zhongcheng/Briggs & Stratton

Rating:6kw、72v、125ah/7.5/8.6/8.5/9.9kw

Rated load:300Kg

Product Information

Products

GC-T390 crawler skid steer loader is specially designed for lightweight work and narrow space. It offers a wide range of power options, including electric, Kopper, Runton, Zhongcheng and Bailiton, etc. The electric model realizes zero-emission and low-noise operation with its 6kw power, 72v voltage and 125ah capacity, while the fuel model delivers stable power output with its single-cylinder naturally-aspirated engine with a rated power of 7.5-9.9kw, and meets the stringent emission standards of EPA/ERUO5 in its entire lineup. 1070kg of operating mass is matched with 200Kg of rated load, 0.12m³ of bucket volume and 3.5KN of maximum operating capacity. With a mass of 1070kg, a rated load of 200Kg, a bucket capacity of 0.12m³ and a maximum lifting force of 3.5KN, combined with the 1807245 track design, it can efficiently accomplish the tasks, whether it is the delicate handling of indoor decoration or the loading and unloading of materials in complicated terrains.


Usage Scenarios

Indoor refinement work: In the indoor decoration scene of residential buildings and office buildings, the vehicle width of 960mm and the height of 1250mm can easily pass through narrow hallways and elevators; the ultra-short tail design of 220mm makes the steering flexible and free from lagging, and the 0.12m³ bucket with the working triple of 9s quickly removes construction garbage and carries lightweight decoration materials, which makes the indoor construction more efficient.


Garden micro-landscaping: In the garden micro-landscaping construction in parks and courtyards, GC-T390 can accurately complete small-scale seedling transplanting and landscape stone handling with a bucket turning angle of 27°-114°; the adjustable driving speed of 0-6km/h is suitable for the rhythm of fine work, and the 230mm ground clearance and crawler configuration make it possible to move forward steadily even when working on soft lawns, without damaging the ground.


Short-distance transportation in agricultural greenhouses: In agricultural greenhouses, the electric model has zero emission and no pollution, which is suitable for handling fertilizers, vegetables and fruits in closed space; the fuel model has stable and long-lasting power, and the 5L fuel tank meets the daily operational needs; the 1807245 track provides strong grip, which enables the truck to drive smoothly on the wet and muddy ground in the greenhouses, and the 200Kg rated load can easily cope with short-distance transportation tasks in greenhouses.


Municipal narrow road maintenance: In municipal maintenance work in narrow streets and alleys, such as pipeline maintenance and road repair material transfer, GC-T390's compact body and flexible maneuverability enable it to travel freely in limited space and efficiently complete the work to ensure the normal operation of urban infrastructure.


Main parameters

Model

GC-T390

Engine model

Electric/KOOP/RATOGH/Zhongcheng/Briggs & Stratton

Rated power

6kw、72v、125ah/7.5/8.6/8.5/9.9kw

Cylinder

1

Intake

Naturally aspirated

Emission standard

Euro 5/EPA

Rated load

200Kg

Maximum load

300Kg

Maximum digging force

3.5KN

Bucket volume

0.12m³

Travel speed

0-6km/h

Operating triple and

9s

Operating system pressure

17bar

Fuel tank volume

5L

Operating mass

1200KG

Tyre type

180*72*45

Overall height

1250mm

Overall length with standard bucket

2400mm

Vehicle width

960mm

Overall length without bucket

1900mm

Bucket width

1050mm

Tail length

220mm

Maximum operating height

2620mm

Height to bucket pins

2000mm

Maximum height of the bucket lying flat

1830mm

Unloading height

1470mm

Unloading distance

600mm

Wheelbase

1300mm

Ground clearance

230mm

Bucket tipping angle at ground level

27°

Tipping angle of the bucket at its highest point

114°


Why GC-S460

  1. Diversified power, full coverage of scenes: electric and a variety of fuel power options, electric models are quiet and environmentally friendly, suitable for indoor, shed and other closed scenes; fuel models are reliable power to meet the needs of outdoor operations, no matter what kind of working conditions can find the best power program.


  2. Compact and flexible, the king of narrow space: 960mm width, 1250mm height and 220mm short tail, with the compact body design, it can travel freely and steer flexibly in narrow spaces such as narrow hallways and alleys, and there is no dead corner in the operation.


  3. High-efficiency light load, energy-saving and reliable: 200Kg rated load and 0.12m³ bucket volume, combined with 3.5KN maximum lifting force and 17bar working system pressure, it can efficiently complete the light-weight material handling; 9s working triple and greatly improve the efficiency, and the 5L fuel tank (fuel model) saves the energy consumption and reduces the cost of use.


  4. Crawler escort, no obstacle in complex terrain: 1807245 crawler and 230mm ground clearance provide strong grip and passability, easily dealing with mud, steep slopes, gravel and other complex terrain, ensuring smooth operation.


  5. Environmental compliance and wider application: It meets the EPA/ERUO5 emission standard without environmental policy restriction, and can be widely used in renovation, gardening, agriculture, municipal services and other fields, making it an all-around helper for lightweight operations.


Contact us today for customized configurations and real-time quotes.
