GC-T604L

Basic parameters

Body Size:2350mm×1250mm×1230mm

Horsepower:60hp

Total Weight:1500kg

Product Information

Product Description

The GC-T604L , combining strong power and excellent performance, is a powerful assistant for agricultural production. It is crafted for efficient operation, whether it is cultivating and sowing farmland, rotary plowing or transportation, it can easily cope with it, helping you to greatly improve the efficiency of agricultural production.


Scenarios

It is suitable for a wide range of farmland environments, and can excel in both large-area farming in plain areas and complex terrain in hills and mountains. It can be widely used in different planting areas such as rice fields, wheat fields, orchards, etc. It meets the diversified operational needs of ploughing, land preparation, fertilizer application, transportation, etc. It is the ideal choice for family farms, professional cooperatives and large agricultural growers.


Main parameters

Model

GC-T604L

Horsepower

60hp

Engine power

44.5kW

Drive form

4WD

Gearing

8+2 (high and low speeds)

High traction

17.4KN

Overall dimensions

2350mm×1250mm×1230mm

Wheelbase

1850m

Front wheelbase

600-1300mm

Rear wheelbase

950-1600mm

Tires

6.0-12

Overall weight

1500kg

Power output shaft speed

720R/min

Speed

1.73~29.27Km/h

Chassis height

240mm

Working speed

3-4 acres/hora

Rotary width

130-160cm

Lifting power

Fuerte elevación y descenso hidráulicos

Variable speed rear axle

Puente lastrado


Why choose  GC-604L

  1. Powerful power: Equipped with Weifang series high-performance diesel engine, 36.85KW power and 50 HP configuration, the power is surging, facing hard land or heavy-duty operation is also effortless.


  2. Adaptation to all terrains: The four-wheel drive type combined with reasonable wheelbase and wheelbase design, as well as the high chassis of 240mm, even in muddy and bumpy terrain, it can drive stably, with excellent passability.


  3. Efficient and flexible: 8+2 high and low speed gears with a forward speed range of 1.73~29.27Km/h, which allows you to control both fine work and quick transfer; the working speed of 3-4 mu/hour and the rotary plowing width of 130-160cm greatly improve the working efficiency.


  4. Stable and Reliable: The heavy bridge's variable-speed rear axle and the hydraulic strong lifting and lowering system ensure that the whole machine has a solid structure, and the working process is smooth, efficient, and durable.


Contact us today for customized configurations and real-time quotes.
