GC-T460 crawler skid steer loader is a high-performance equipment specially designed for diversified operation scenarios. It offers a variety of power options, such as electric, Kopper, Runton, and Paragon, the electric model with 8kw power, 72v voltage, and 200ah capacity, realizing zero-emission and low-noise operation; the fuel model outputs 15/19.2/17kw rated power, respectively, and the twin-cylinder naturally-aspirated engine is powerful and stable, and the whole series meets the stringent emission standards of Euro 5/EPA. 1200KG operating quality With 300Kg rated load, 0.12m³ bucket volume and 4.5KN maximum digging force, together with the 1807235 track design, it is easy to handle both fine work in narrow space and heavy load handling in complex terrain.
Usage Scenarios
Interior Decoration and Remodeling: In the renovation of residential and office buildings, the 1050mm width and 1300mm height of the truck can freely enter and exit elevators and narrow hallways; the 500mm short tail design provides flexible steering and avoids collision; the 0.12m³ bucket with 9s work triple and quickly removes construction debris and removes renovation materials, greatly improving construction efficiency.
Small-scale gardening projects: In the greening construction of parks and courtyards, GC-T460 can accurately complete the transplanting of seedlings and earth moving with a bucket turning angle of 27°-114°; the adjustable driving speed of 0-6km/h is suitable for different operating rhythms, and the 110mm ground clearance and crawler configuration can work stably on uneven ground, helping to create exquisite garden landscapes.
Agricultural greenhouse and orchard operation: Shuttle through the narrow passage of agricultural greenhouses and orchards, the electric model has no exhaust emission, which is suitable for handling fertilizers, fruits and vegetables in a closed environment; the fuel model has long-lasting power, which meets the demand for long-time continuous operation. 1807235 track provides strong grip, which enables it to drive smoothly on wet and muddy ground, and the rated load of 300Kg is easy to cope with the daily transportation of agricultural materials.
Municipal Maintenance and Small Infrastructure: In small infrastructure and maintenance work in city streets and neighborhoods, such as sidewalk repair and material transfer for pipeline laying, GC-T460's compact body and flexible maneuverability enable it to work efficiently in limited space, adding bricks and mortar to urban construction.
Main parameters
| Model | GC-T460 |
Engine model | Electric/KOOP/RATOGH/Briggs & Stratton |
Rated power | 8kw、72v、200ah/15/19.2/17kw |
Cylinder | 2 |
Intake | Naturally aspirated |
Emission standard | Euro 5/EPA |
Rated load | 300Kg |
Maximum load | 400Kg |
Maximum digging force | 4.5KN |
Bucket volume | 0.12m³ |
Travel speed | 0-6km/h |
Operating triple and | 9s |
Operating system pressure | 17-21bar |
Fuel tank volume | 10L |
Operating mass | 1200KG |
Tyre type | 180*72*45 |
Overall height | 1300mm |
Overall length with standard bucket | 2229mm |
Vehicle width | 1024mm |
Overall length without bucket | 1700mm |
Bucket width | 1070mm |
Tail length | 220mm |
Maximum operating height | 2560mm |
Height to bucket pins | 2071mm |
Maximum height of the bucket lying flat | 2024mm |
Unloading height | 1376mm |
Unloading distance | 231mm |
Wheelbase | 800mm |
Ground clearance | 195mm |
Bucket tipping angle at ground level | 25° |
Tipping angle of the bucket at its highest point | 88° |
Why GC-S460
Diversified power, adaptable to all scenes: electric and fuel multiple power combinations, electric models are quiet and environmentally friendly, suitable for indoor, greenhouses and other environmentally sensitive scenes; fuel models have long-lasting power, capable of outdoor complex working conditions, to meet the needs of all types of operating environments.
Compact and Flexible, Smooth Operation in Narrow Spaces: With 1050mm width, 1300mm height, 500mm short tail, and 800mm wheelbase, it can travel freely and steer flexibly in narrow alleys, indoor corridors and other narrow spaces, and easily arrive at the workplace.
Efficient operation and reliable performance: 300Kg rated load and 0.12m³ bucket volume, combined with 4.5KN maximum digging force and 17-21bar working system pressure, efficiently complete the material handling, loading and unloading; 9s quick work three and greatly shorten the working time. 10L fuel tank (fuel model) and stable power system, reduce the interruption of the operation and guarantee the continuous and efficient operation.
Crawler support, no worry about complicated terrain: 1807235 crawler model combined with 110mm ground clearance, strong grip and good passability, whether it is muddy farmland, rugged mountain roads, or soft sand, can work smoothly, as if walking on the ground.
Environmental compliance, wide range of applications: meets Euro 5/EPA emission standards, no environmental restrictions; widely used in renovation, garden construction, agricultural production, municipal maintenance and other fields, providing reliable operational solutions for various industries.
Contact us today for customized configurations and real-time quotes.
